- Arc Flash rating AND Class 2 Leading Edge rating for the first time in an SRL.
- Features 100% Kevlar version of FallTech's innovative EdgeCore synthetic lifeline
- Compact design elevates the SRDs to align optimally with worker motion, increasing both comfort and productivity
- Features comprehensive fall clearance charts and tables inside the Kevlar/Nomex energy absorber cover
- Internal mechanism design minimizes unintentional lockups to keep you moving freely and productively
- Suitable for below D-ring tie-off up to five feet and leading edge exposures and hazards, including steel and precast concrete
- Rated for workers weighing up to 420 pounds, including clothes, tools, gear, etc.
- Complies with ANSI Z359.14-2021 Class 2 SRL-P. Learn more and download White Paper
- Meets ASTM F887 Standards
Material Specifications:
- Lifeline: EdgeCore; 5,000 lb min. static strength
- Energy Absorber: Polyester tear-away
- Anchorage Connector: Plated alloy steel; 5,000 lb min. static strength with 5,000 lb gate strength
- Dorsal Connector: Aluminum alloy; 3,600 lb min.
Performance Specifications:
- Static Strength: 3,600 lb min.
- ANSI SRL Class: Class 2 SRL-P
- Avg. Arrest Force: 1,350 lb max.
- Max. Arrest Force: 1,800 lb
- Max. Arrest Distance: 42"
- ANSI User Capacity: 130 to 310 lb max.
- OSHA User Capacity: 130 to 420 lb max.
